Technical support
A.2 Problem solving
SIMATIC IPC547D
114 Operating Instructions, 06/2011, A5E03473780-01
Problem Possible cause Possible remedy
After changing the hard
disk, the system does not
boot from the RAID system
RAID system does not have
highest boot priority
BIOS setup, boot menu:
 Permit RAID system in the boot priority
 Set the RAID system to be first in the boot priority order.
After changing the hard
disk, "unused" is indicated
for the relevant SATA port
The system was booted
without a functioning hard
disk (the removable
cartridge was possibly not
turned on)
Reboot the system with a functioning hard disk
Computer does not boot or
"Boot device not found" is
displayed
 The boot device is not
permitted
 The boot device is not in
first place of the boot
priority in the BIOS
setup
 The boot data carrier is
set up with GPT and
UEFI boot is deactivated
in the BIOS setup
 In the BIOS setup, "Boot" menu, permit the boot device in
the boot priority
 In the BIOS setup, "Boot" menu, change the boot priority
of the boot device
 Activate UEFI boot in the BIOS setup.
The startup of a Windows
operating system on a GPT
data carrier is aborted with
the following error message:
"Status: 0xc0000225 Info:
The boot selection failed
because a required device
is inaccessible"
The boot parameters in the
boot loader file "BCD" are
incorrect or damaged.
Execute "Startup and Repair" from Microsoft Windows:
1. Insert the Recovery DVD into the optical drive.
2. Start the boot manager using the <F12> key during
booting
3. Select the line with "UEFI" in front of the name of the
optical drive
4. Click "Next" in the language selection window
5. In the following "Install Windows" dialog, click on "Repair
your computer" or press the <R> key. The "System
Recovery Options" dialog appears. The system is checked
for errors.
6. Next, click "Repair and restart"
