Commissioning the device
4.3 Information on optional features
SIMATIC IPC547D
42 Operating Instructions, 06/2011, A5E03473780-01
Procedure
1. Select "Boot > Hard Drive > <Drive name> e.g. STxxxxxxxxx- SATA1".
2. Press the "+" key and move the entry upward in the boot sequence.
Note
The drive letters for the partitions on both drives are assigned by the operating system
used. You can change these in the Control Panel as required.
4.3.4 RAID system
4.3.4.1 RAID1 system
This is a RAID1 system configuration (data mirroring with two hard disks). This means that if
there is a defective hard disk or there are cable problems, the system can continue to
operate in one channel achieving a high degree of system availability.
Note
You will find information about the Intel RAID controller in the RAID documentation in the
"Drivers\RAID\Intel" directory on the "Documentation and Drivers" DVD that ships with the
product.
