Device maintenance and repair
7.1 Removing and installing hardware components
SIMATIC IPC547D
70 Operating Instructions, 06/2011, A5E03473780-01
6. Remove the highlighted screws.
7. Take the fan out of the enclosure.
Procedure - Installing the fan
To install the fan, follow the steps for removing it in reverse order. During installation, make
sure that the arrow on the fan housing points away from the fan bracket.
7.1.5 Replacing the backup battery
Note before you replace the battery
Note
Batteries are wearing parts. Backup batteries should be replaced at intervals of 5 years in
order to maintain PC functionality.
CAUTION
Risk of damage!
The lithium battery may only be replaced with an identical battery or with a type
recommended by the manufacturer. Information on original spare parts for SIMATIC IPCs is
available at After sales information system from SIMATIC IPC
(http://www.siemens.com/asis
)
Disposal
CAUTION
Depleted batteries must be disposed of in accordance with local regulations.
