Technical specifications
8.4 Technical specifications
SIMATIC IPC547D
Operating Instructions, 06/2011, A5E03473780-01
95
8.4 Technical specifications
8.4.1 General technical specifications
NOTICE
Applicability of technical specifications
The following technical specifications only apply under the following conditions:
The device is in good working order.
The fan cover and filter mat are installed.
The device is closed.
Order numbers 6AG4104-2....-.... (for details, refer to the ordering
documentation)
Dimensions 433.5 × 176.5 × 445.5 (W × H × D in mm)
You will find detailed information on dimensions in the chapter
"Dimension drawing of the device (Page 93)".
Weight Min. 16 kg, max. 23 kg
Supply voltage (V
N
)
100 V AC to 240 V AC (-15%, +10%)
Redundant power supply:
2 × 100 V AC to 240 V AC (-15%, +10%)
Input current AC
Continuous current up to 6 A (at 100 V) 3 A (at 240 V)
During startup up to 30 A and 5 ms
Frequency 50 to 60 Hz
minimum 47 Hz to maximum 63 Hz, sinusoidal
Transient voltage interruption 20 ms at 93 V
max. 10 events per hour; recovery time of at least 1 s
Power consumption With 210 W secondary:
Redundant AC power supply: Max. 300 W at 70% efficiency
AC power supply: Max. 270 W at 80% efficiency
Power loss/heat emission 300 W = 300 J/s = 0.28 BTU/s
270 W = 270 J/s = 0.26 BTU/s
Current output (DC) +5 V/26 A, +3.3 V/24 A in total 190 W permitted
+12 V/15 A, +12 V/15 A, -12 V/0.2 A, +5 Vaux/2 A
The total sum of all voltages is max. 210 W.
Noise emission < 45 dB (A) to DIN 45635
(40 dB(A) at 20 °C, Windows idle mode)
Degree of protection
IP 30 with closed front cover
IP 20 on the rear according to EN 60529
Dust protection With the front panel closed in accordance with IEC 60529
Filter class G2 EN 779, 99 % of particles > 0.5 mm are filtered
