Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC547D
36 Operating Instructions, 06/2011, A5E03473780-01
3.3.4 Connect device to networks
The following options are available for integrating the device in existing or planned system
environments and networks.
Ethernet
Wake on LAN and Remote Boot are supported.
You can use the integrated Ethernet interfaces (10/100/1000 Mbps) for communication and
data exchange with automation devices, such as SIMATIC S7.
You need the "SOFTNET S7" software package for this.
PROFINET
PROFINET can be operated via:
● Standard Ethernet interfaces (RT)
SIMATIC NET
Use this software package to create, operate and configure an innovative network for Field &
Control level. Information on this can be found on the SIMATIC NET Manual Collection CD.
The software package and the documentation are not included in the product package.
Additional information
You can find additional information on the Internet at: Technical Support
(http://www.siemens.de/automation/csi_en_WW
)
3.3.5 Multi-monitoring
You can operate up to four monitors in combination with the integrated graphics controller or
with the optional NVS300 graphics card. Parameter assignment is performed via the Control
Panel in Windows.
