8.4 Technical specifications
SIMATIC IPC547D
96 Operating Instructions, 06/2011, A5E03473780-01
Safety
Protection class Protection class I compliant with IEC 61140
Safety regulations IEC60950-1, EN60950-1, UL60950-1,
CSA C22.2 No 60950-1-07
Electromagnetic compatibility
Emitted interference (AC) EN 61000-6-3; EN 61000-6-4;
CISPR 22/EN 55022 Class B; FCC Class A;
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity:
Mains borne disturbance variables
on supply lines
± 2 kV; in accordance with IEC 61000-4-4; Burst
± 1 kV; in accordance with IEC 61000-4-5; Surge sym
± 2 kV; in accordance with IEC 61000-4-5; Surge asym
Noise immunity on signal lines ± 2 kV (in accordance with IEC 61000-4-4; Burst; length > 30 m)
± 1 kV (in accordance with IEC 61000-4-4; Burst; length < 30 m)
± 2 kV (in accordance with IEC 61000-4-5; Surge, length >
30 m)
Immunity to discharges of static
electricity
± 4 kV, contact discharge (to IEC 61000-4-2)
± 8 kV, atmospheric discharge (to IEC 61000-4-2)
Immunity to RF interference 1 V/m, 2-2.7 GHz, 80% AM (to IEC 61000-4-3)
10 V/m, 80-1000 MHz und 1.4 - 2 GHz, 80% AM; (conforms to
IEC 61000-4-3)
10 V, 10 kHz-80 MHz; (conforms to IEC 61000-4-6)
Magnetic field 100 A/m, 50 Hz / 60 Hz; (to IEC 61000-4-8)
Ambient conditions
Climatic ambient conditions
Temperature Tested in accordance with IEC 60068-2-2, IEC 60068-2-1,
IEC 60068-2-14
During operation
Gradient
Storage/transportation
Gradient
+5 °C to +40 °C
1
Max. 10 °C/h, no condensation
–20 °C to +60 °C
Max. 20 °C/h, no condensation
Relative humidity Tested in accordance with IEC 60068-2-78, IEC 60068-2-30
During operation
Gradient
Storage/transportation
Gradient
5% to 80% at 25° C, no condensation
Max. 10 °C/h, no condensation
5% to 95 % at 25° C, no condensation
Max. 20 °C/h, no condensation
Atmospheric pressure
During operation
Storage/transportation
1080 to 795 hPa,
corresponds to an elevation of -1000 to 2000 m
1080 to 660 hPa,
corresponds to an elevation of -1000 to 3500 m
