Siemens SIMATIC IPC547D User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547D
Operating Instructions, 06/2011, A5E03473780-01
97
Mechanical ambient conditions
Vibration
 Operation
2)
 Storage/transportation
Tested in accordance with IEC 60068-2-6, 10 cycles
20 to 58 Hz, amplitude 0.015mm; 58 to 200 Hz: 2m/s
2
5 to 8.51 Hz, amplitude 3.5 mm; 8.51 to 500 Hz: 9.8 m/s
2
Resistance to shock
 Operation
2)
 Storage/transportation
Tested in accordance with IEC 60068-2-27
Half-sine: 9.8 m/s
2
, 20 ms, 100 shocks per axis
Half-sine: 250 m/s
2
, 6 ms, 1000 shocks per axis
Special features
Quality assurance In accordance with ISO 9001
1
No burner operation
At +5 °C to +35 °C without restrictions, even burner operation, CPU up to power loss 95
W, see notes on retrofitting
2
When using a hard disk in a removable rack, the device should generally be free of
mechanical disturbances.
When using a DVD burner, the device should generally be free of mechanical
disturbances during burning.
Motherboard
Processor
 Intel® Pentium Dual-Core G850 (2 cores, 2.9 GHz, 3 MB
cache, EM64T, VT)
 Intel® Core™ i5-2400 (4 cores/4 threads, 3.1 GHz Turbo
Boost, 6 MB cache, EM64T, VT-x/VT-d, iAMT
 Intel® Core™ i7 -2600 (4 cores/8 threads, 3.4 GHz, 8 MB
cache, Turbo Boost 2.0, EM64T, VT-x/-d, iAMT)
Chipset Q67 Express
RAID (on-board) Intel® PCH with Intel® Rapid Storage Technology
Slots for RAM modules 4 X DIMM socket for DDR3, expandable up to max. 32 GB
Main memory 1 GB to 16 GB DDR3 1333 SDRAM (PC3-10600), max. 3.2 GB
for 32-bit operating system and applications can be used (for
equipment, see order documents)
Expansion slots
 4 × PCI
 1 × PCIe x8 (1 lane)
 1 × PCIe x16 (4 lanes)
 1 × PCIe x16
You can use modules with a length of up to 312 mm.
