Technical specifications
8.4 Technical specifications
SIMATIC IPC547D
98 Operating Instructions, 06/2011, A5E03473780-01
Max. permitted power
consumption
PCIe x1, x8 (1 lane) and x16 (4
lanes) slot
Max. permitted power
consumption PCIe x4 module:
Max. permitted power
consumption
PCIe x16 slot
Max. permitted power
consumption per PCI slot (5 V, 32-
bit)
Max. permitted power loss per PCI
slot
PCI modules with exclusive 5 V
supply
Max. permitted power loss over all
slots
3.3 V 3 A; 12 V 2.1 A; 3.3 Vaux 0.4 A
3.3V 3A; 12V 2.1A; 3.3Vaux 0.4A
PCIe x16 module: 3.3 V 3 A; 12 V 2.1 A;
3.3 Vaux 0.4 A
5 V, 5 A or 3.3 V, 7A; 12 V 0.5 A; –12 V 0.05 A;
3.3 Vaux 0.4 A
All voltages must not exceed 25 W in total.
All modules must not consume more than 25 W in total.
Total power consumption of 80 W must not be exceeded.
In total, the 3.3 V
aux
current of 1.2 A must not be exceeded.
Drives (for configuration details, refer to the order documentation)
Hard disk drive SATA Internal installation or in removable rack
1
:
 500 GB or 1 TB, internal
 RAID1 1 TB (2x 1 TB), internal
 Solid state drive SATA 50 GB (SLC), internal
 500 GB in movable rack; front
 2x 500 GB in removable rack; front
 RAID1 1 TB (2x 1 TB) in removable rack; front
 RAID5 2 TB (3x 1 TB) in removable rack; at front
2
 Solid-state drive SATA 50 GB (SLC) in removable rack; at
the front
 RAID1 1 TB (2x 1 TB) + solid state drive SATA 50 GB (SLC)
in removable rack, at the front
DVD-ROM 5.25" SATA
Read:
 DVD ROM: Single layer 16x, dual layer 12x
 DVD+R/RW, DVD-R/RW 8x, DVD-RAM 2x
 CD-ROM, CD-R 32x, CD-RW 20x
