Overview
1.1 Product description
SIMATIC IPC647D
12 Operating Instructions, 01/2014, A5E32996306-AA
Monitoring functions
Temperature
• Overshoot/undershoot of permissible operating
temperature
• Messages can be evaluated by an application program.
Fan
• Speed monitoring
• Messages can be evaluated by an application program.
Watchdog
• Monitoring of the IPC
• Monitoring time can be parameterized in software
• Restart can be parameterized in the event of a fault
• Messages can be evaluated by an application program.
Status LEDs
• POWER (internal power supply unit, PC switched On)
• HDD (access to hard disk drive)
• ETHERNET 1, ETHERNET 2 (Ethernet status,
"heartbeat")
• PROFIBUS/MPI (activation display of the PROFIBUS/MPI
interface), optional product feature
• SF PROFINET (status display of the CP 1616 onboard
interface), optional product feature
• WATCHDOG (Watchdog function/error display)
• TEMP (temperature status)
• FAN (speed monitoring)
• HDD0 Alarm, HDD1 Alarm: RAID status message in
conjunction with SIMATIC monitoring software (only with
RAID option)
Basic variant
Motherboard Motherboard without fieldbus,
Intel® DH82C226 Express Chipset
Bus board
PCI, PCIe x4, PCIe x16, 2 variants
Processor
• Intel® Xeon™ E3-1268L v3 2.3 (3.3) GHz, 4 cores, GT2,
8 MB SLC, HT
• Intel® Core™ i5-4570TE 2.7 (3.3) GHz, 2 cores, GT2, 4
MB SLC, AMT
• Intel® Core™ i3-4330TE 2.4 GHz, 2 cores, GT2, 3 MB
SLC, AMT
RAM expansion Up to 32 GB SDRAM DDR3 1600MT/s
4 DIMM base with or without ECC
1
Drives
Hard disks
3.5" SATA 6 Gbit/s, 500 GB / 1000 GB
Optical drive
Slimline SATA
1
Memory expansions ≥4 GB can only be used in combination with 64-bit operating systems.
