Overview
1.1 Product description
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
11
Design
• 19” rack, 2 HU
• Rugged panel-mount housing, all metal
• Prepared for mounting telescopic rails
• Can be mounted horizontally
• Lockable front cover as access protection
Enclosure
• Dust protection by
means of overpressure ventilation using
bearing seated front fan through filter
• Enclosure cover fastened with a single screw
• Front fan can be exchanged without tools
• Card retainer for reliable operation of PC modules under
vibration and shock conditions
Drive bays
• 2 × removable drive bays, slimline or
• 2 × 3.5" drive in vibration-damped drive cage and
• 1 × slimline DVD format
Slots for expansion cards (long) Max. 4 slots, equipment PCI/PCIe, depending on
Graphics
• CRT (via DVI-I VGA adapter): Up to 2560x1600 at 120 Hz
/ 32-bit color depth
• LCD via DVI-D: Up to 2048 x 1152 at 60 Hz, 32-bit color
depth
• LCD via DisplayPort: Up to 4096 x 1152 at 24 Hz, 32-bit
color depth
12 Mbps (isolated potential, compatible to CP -5622), optional
10/100 Mbps (CP 1616 onboard), three RJ45; optional
Ethernet 2 x 10/100/1000 Mbps (two RJ45)
Wake on LAN, Remote Boot and teaming are supported
2 x front panel, 4 x rear panel, 1 x internal; (high current)
Serial COM1 (V.24), COM2 (V.24) optional, through slot plate
LPT optional, through slot plate adapter
Monitor
• 1 x DVI-I (for DVI-D or VGA using cable adapter)
• 2 × DisplayPort
• 2 × DVI-D/VGA with Dual Head graphics card (optional,
via cable adapter)
Microphone, Line out / Headset
Power supply 100 VAC to 240 VAC, wide range; with short-term power
failure backup in accordance with NAMUR: Max. 20 ms at
0.85 rated voltage
