Siemens SIMATIC IPC647D

Technical specifications
8.5 Hardware description
SIMATIC IPC647D
136 Operating Instructions, 01/2014, A5E32996306-AA
8.5.1.4
External interfaces
Interface
Position
Connector
Description
COM1
External
X30
9-pin standard plug
COM2
Internal
X504
10-pin module plug for ribbon cable connection
LPT1
Internal
X501
26-pin module plug for ribbon cable connection
PS/2 mouse External X25 P2
(7 to 12)
6-pin, miniature DIN socket (top socket)
PS/2 keyboard External X25 P1
(1 to 6)
6-pin, miniature DIN socket (bottom socket)
USB 3.0
External
X2 A, B
USB3 Port 0, 1; USB2 Port 0, 1 interface side
Internal
X563
USB3 Port 2; USB2 Port 2 (dongle interface)
Internal
X502
USB3 Port 3; USB2 Port 3 (connection of display module)
USB 2.0
External
X4 A, B
USB2 Port 4, 5 interface side
PROFIBUS/MPI
External
X600
9-pin, standard socket, electrically isolated interface
PROFINET
External
X3
Port 0, 1, 2 RJ45
Ethernet 1 and 2
External
X4, X2
RJ45
DVI-D
External
X70
24-pin DVI-D female connector
DPP
External
X71
20-pin DisplayPort connector
DPP External X72 20-pin DisplayPort connector
Microphone External X90
(bottom)
6-pin 3.5 mm jack
Line out
External
X90 (top)
6-pin 3.5 mm jack
