Technical specifications
8.5 Hardware description
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
133
8.5.1.2
Technical features of the motherboard
Component /
interface
Description
Parameters
Chipset Single chipset
• Mobile Intel
®
8 chipset DH82C226 Express
(Platform Controller Hub)
BIOS Update by means of
software
• Insyde modified by Siemens
CPU Intel
®
Core™ i
• VT and multimedia support
• Turbo Boost and AMT, depending on CPU
• Onboard cache with 3M/4M depending on
CPU
Memory 4 DIMM module slots,
max. 8 GB per module
• Data width of 64/72 bits (without ECC / with
ECC)
• 3.3 V
• DDR3 1600-SDRAM in accordance with PC3-
12800 specification
• 2 to 4 Gbit chip size on the module
• 1600 MT/sec transfer rate
• Variable from 2 GB to 8 GB / DIMM
• With and without ECC
Graphics Integrated in the CPU
• Intel® HD Graphics Controller, P4600/P4700
GT1/GT2
Graphics Controller integrated in processor
with three independent 2-D and 3-D Engines.
• Intel® DH82C226 Express
(Platform Controller Hub)
– VGA: 2560 × 1600/32-bit color depth/120
Hz
– DVI-D:
2048 × 1152/32-bit color depth/60 Hz
DisplayPort: 4096 × 2160/32-bit color
depth/24Hz
• Graphics memory:
Up to 1.7 GB, used in system memory, 32 MB
reserved.
Expansion card slots PCI, PCIe-Gen1, PCIe-
Gen2
• 1 PCI 32-bit / PCIe-Gen2 4 Lanes. Type
PCIe-x16 direct plug socket
• 1 PCIe-Gen3 16 Lanes, type PCIe-x16 direct
plug socket
