Siemens SIMATIC IPC647D

Technical specifications
8.5 Hardware description
SIMATIC IPC647D
134 Operating Instructions, 01/2014, A5E32996306-AA
Component /
interface
Description
Parameters
SATA interface
4
Various SATA modes,
AHCI, RAID 0, etc. can
be set
• 6 interfaces
• Compatible to SATA-150/300/600
• Supports NCQ (Native Command Queuing)
• 6 connectors
Keyboard PS/2 keyboard interface
• Standard
Mouse PS/2 mouse interface
• Standard
Serial
• COM1, 9-pin sub D
• COM2, 9-pin
• V.24
Parallel Standard, bi-directional,
EPP and ECP mode
Module connector for ribbon cable, with 9-pin sub
D at slot cover
PROFIBUS/MPI
2
SIMATIC S7
communication interface
Electrically isolated
1
compatible to CP-5622, 12
Mbps
PROFINET
2
Communication interface
for PROFINET
IO applications and
SIMATIC installations
• 10/100 Mbps, electrically isolated
1
• CP -1616 compatible 3-port interface
USB
Universal Serial Bus
USB 2.0 3 high-current (500 mA) USB -2.0 ports, of those:
• 1 on the front
• 2 on the back
USB 3.0 4 high-current (500 mA) USB -3.0 ports, of those:
• 1 on the front
• 2 on the back
• 1 inside
Ethernet (two
interfaces)
10BaseT/100Base-
TX/1000Base-TX
Ethernet 1:
Intel
®
Gigabit Network
Connection (WGI210IT)
Ethernet 2:
Intel
®
Gigabit Network
Connection (WGI217LM)
• 10/100/1000 Mbps, electrically isolated
1
• Wake on LAN, remote boot
• AMT-capable
5
, teaming-capable
• Supports jumbo frames up to 9014 bytes
• With teaming capability
• Supports jumbo frames up to 9014 bytes
1
Electrical isolation within the safety extra-low voltage circuit (SELV)
2
Optional product variant
3
Depends on the CPU type
4
Depends on the selected device configuration
A floppy disk drive cannot be ordered using the configurator
5
AMT and teaming cannot be used simultaneously on the Ethernet interface
