Siemens SIMATIC IPC647D

Technical specifications
8.6 BIOS description
SIMATIC IPC647D
180 Operating Instructions, 01/2014, A5E32996306-AA
8.6.7.2
BIOS beep codes
Below please find the customer-relevant POST codes. Contact Customer Support
(http://www.siemens.de/automation/csi_en_WW
) for information on all other POST codes.
Display
(hex)
Meaning
Description
Remedy
01H SEC_SYSTEM_POWER_ON CPU power on and
switch to Protected mode
Switch to Protected Mode Service case
02H
SEC_BEFORE_MICROCODE_PATCH
Patching CPU microcode
Load CPU Microcode
Service case
03H
SEC_AFTER_MICROCODE_PATCH
Setup Cache as RAM
Set up cache as RAM
Service case
04H SEC_ACCESS_CSR PCIE MMIO Base
Address initial
Initialize PCIE Service case
05H SEC_GENERIC_MSRINIT CPU Generic MSR initial Initialize CPU MS
(Machine Status) Register
Service case
06H
SEC_CPU_SPEEDCFG
Setup CPU speed
Specify CPU speed
Service case
07H SEC_SETUP_CAR_OK Cache as RAM test Carry out RAM Test on
cache
Replacing a
basic module
08H SEC_FORCE_MAX_RATIO Tune CPU frequency
ratio to maximum level
Setting CPU frequency Service case
09H
SEC_GO_TO_SECSTARTUP
Setup BIOS ROM cache
Set up BIOS ROM cache
Service case
0AH SEC_GO_TO_PEICORE Enter Boot Firmware
Volume
Calling up the boot
firmware memory area
Service case
70H PEI_SIO_INIT Super I/O initial Initialization of the Super
I/O
Service case
71H
PEI_CPU_REG_INIT
CPU Early Initial
Initialize CPU Register
Service case
72H PEI_CPU_AP_INIT Multi-processor Early
initial
Multi processor
initialization
Service case
73H PEI_CPU_HT_RESET HyperTransport initial Initialize Hyper Transport
functionality
Service case
74H
PEI_PCIE_MMIO_INIT
PCIE MMIO BAR Initial
Initialize PCIE Register
Service case
75H PEI_NB_REG_INIT North Bridge Early Initial Initialization of the North
bridge
Service case
76H PEI_SB_REG_INIT South Bridge Early Initial Initialization of the South
bridge
Service case
77H PEI_PCIE_TRAINING PCIE Training Training phase of the
PCIE device
Service case
78H
PEI_TPM_INIT
TPM initial
TPM initialization
Service case
79H
PEI_SMBUS_INIT
SMBUS Early Initial
Initialization of the SM Bus
Service case
7AH PEI_PROGRAM_CLOCK_GEN Clock Generator Initial Initializations of the clock
generator
Service case
7BH PEI_IGD_EARLY_INITIAL Internal Graphic device
early initial,
PEI_IGDOpRegion
First initialization of the
graphic connection
Service case
7CH PEI_HECI_INIT HECI Initial Initialization of the Host
Embedded Controller
Interface
Service case
