Technical specifications
8.4 Technical specifications
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
129
● Do not cover the ventilation slots of the enclosure.
● The device meets requirements for fire protection housings to EN 60950-1 and can be
installed without additional fire protection enclosure.
● The connected or built-in peripherals should not introduce a counter emf in excess of
0.5 V into the device.
8.4.3
Current and power requirements
Base system
Component
Voltage
+3.3 V
+5 V
+12 V
+12 V2
-12 V
5 Vaux
Motherboard core i processor
with cooling
1.2 A 2.8 A 0.35 A 5.35 A 0.03 A 0.3 A
Front fan
1.0 A
Fan inside
0.3 A
Motherboard Xeon processor
with cooling
1
1.2 A 2.8 A 0.95 A 5.35A 0.03A 0.3 A
Hard disk drive SATA (typical
values)
0.5 A 0.7 A
Base system (dual core)
1
1.2 A
3.3 A
1.65 A
5.35 A
0.03 A
0.3 A
Slimline drive
1
0.8 A
Single currents ATX, max.
permissible
20 A
2
25 A
2
11 A 14 A
3
0.5 A 2.0 A
4
Single currents ATX redundant,
max. permissible
20 A
2
20 A
2
18 A 18 A 0.8 A 2.0 A
4
Total power consumption,
permissible
185 W
Efficiency of the single and
redundant power supply
1
Approx. 80% (230 VAC ), approx. 80% (120 VAC)
1
Depends on the selected device configuration
2
The maximum total power of the voltage + 5 V and + 3.3 V amounts to 190 W at ATX power
supply and 100 W at ATX redundant.
3
18 A for 20 seconds
4
2.5 A for 10 seconds
Typical power values
Component
Current consumption
(AC-SV, U=230 V)
Power consumption
Base device
0.6 A
130 W
Hard disk drive 1 × 3.5"
0.06 A
13.6 W
Hard disk drives 2 × 3.5"
0.12 A
27.2 W
DVD burner drive
0.05 A
12.7 W
