Siemens SIMATIC IPC647D

Technical specifications
8.4 Technical specifications
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
123
8.4
Technical specifications
8.4.1
General specifications
General specifications
Order number
6AG4112-2...(for details, refer to the ordering documentation)
Dimensions 430 × 88.1 × 444.6 (W × H × D in mm). Detailed dimensional
specifications can be found in section
Dimensional drawing of
the device (Page 121).
Weight
Min. 10 kg, max. 14 kg
Supply voltage (V
N
) 100 to 240 VAC (–15%, 10%), varying voltage; with transient
power failure backup in accordance with NAMUR
Input current AC
Continuous current up to 6 A (up to 30 A for 5 ms at startup)
Line voltage frequency
50 to 60 Hz (min. 47 Hz to max. 63 Hz, sinusoidal)
Transient voltage interruption Min. 20 ms at 93 V
(max. 10 events per hour; recovery time at least 1 s)
Power consumption AC power supply: Max. 240 W at 80% efficiency
Redundant AC power supply: Max. 240 W at 80% efficiency
Power loss / heat emission AC power supply: 240 W = 240 J/s = 0.23 BTU/s
Redundant AC power supply: 240 W = 240 J/s = 0.23 BTU/s
Current delivery (DC) +5 V/30 A + 3.3 V/28 A, max. aggregate power 160 W
+12 V/15 A -12 V/0.5 A -5 V/0.5 A +5 Vaux/2 A
Aggregate power of all voltages max. 190 W
Noise emission < 45 dB(A) at 25 °C according to DIN EN ISO 7779
ODDs not in operation
Degree of protection
IP41 at the front and IP20 at the rear according to IEC 60529
Dust protection With closed front panel
Filter class G2 EN 779, 99% of particles > 0.5 mm are filtered
Safety
Protection class
Protection class I according to IEC 61140
Safety regulations
• IEC 60950-1
• EN 60950-1
• UL 60950-1
• CSA C22.2 No 60950-1-07
