Siemens SIMATIC IPC647D

Technical specifications
8.4 Technical specifications
SIMATIC IPC647D
124 Operating Instructions, 01/2014, A5E32996306-AA
Electromagnetic compatibility (EMC)
Radiated interference EN 61000-6-3, FCC Class A
EN 61000-6-4;
CISPR 22,EN 55022 class B
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity: Mains borne
disturbance variables on supply lines
± 2 kV, according to IEC 61000-4-4, burst
± 1 kV, according to IEC 61000-4-5, surge sym.
± 2 kV, according to IEC 61000-4-5, surge asym.
Noise immunity on signal lines ± 1 kV, according to IEC 61000-4-4; Burst; Length < 30 m
± 2 kV, according to IEC 61000-4-4; Burst; Length > 30 m
± 2 kV, according to IEC 61000-4-5; Length > 30 m
Immunity to discharge of static
electricity
±6 kV contact discharge, according to IEC 61000-4-2
± 8 kV air discharge, according to IEC 61000-4-2
Immunity to RF interference
• 10 V/m, 80...1000 MHz and 1.4...2 GHz,
80% AM 1 kHz, according to IEC 61000-4-3
• 3 V/m 2...2.7 GHz, 80% AM 1kHz,
according to IEC 61000-4-3
• 10 V, 10 KHz...80 MHz, 80% AM 1 kHz,
according to IEC 61000-4-6
Magnetic field
100 A/m, 50 Hz/60 Hz, nach IEC 61000-4-8
Climatic ambient conditions
Temperature
Tested in accordance with IEC 60068-2-2, IEC 60068-2-1,
IEC 60068-2-14
During operation
Gradient
+5 to +35 °C, without restriction under the provided technical
specifications
+5 to +40 °C, ODD operation, total power loss of expansion modules
less than 55 W
+5 to +45 °C, no ODD operation, total power loss of expansion cards
less than 55 W
+5 to +50 °C +
)
No ODD operation, n
o HDD operation in the removable
drive bay
Max. 10 °C/h, no condensation
+)
Power dissipation of the expansion cards in total less than 30 W
Storage/transport
Gradient
–20 °C … +60 °C
max. 20° C/h, no condensation
Relative humidity
Tested in accordance with IEC 60068-2-78, IEC 60068-2-30
In operation
Gradient
5% to 80% at 25 °C (no condensation)
Max. 10°C/h, no condensation
Storage/transport
Gradient
5% to 95% at 25 °C (no condensation)
Max. 20 °C/h, no condensation
Atmospheric pressure
During operation 1080 to 795 hPa,
corresponds to an elevation of -1000 to 2000 m
Storage/transport 1080 to 660 hPa,
corresponds to an elevation of -1000 to 3500 m
