Device maintenance and repair
7.3 Removing and installing hardware
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
99
Removing the motherboard
Requirement
● The device is fully disconnected from the mains voltage, see chapter "Switching off the
device (Page 51)".
● The device is open, see the section "Open the device. (Page 63)".
● The bus frame has been removed, see chapter "Removing and installing bus frame
(Page 68)".
● The processor cooler has been removed, see chapter "Removing and installing the
processor cooler (Page 97)".
● 1 motherboard
Information about original spare parts for SIMATIC IPCs is available on the Internet at:
SIMATIC IPC after-sales information system (http://www.siemens.com/asis
).
The motherboard is supplied as a spare part with soldered-on processor - but without
processor heat sink, memory modules and bus board.
● 1 hex key 4.5 mm
● T10 screwdriver
