Siemens SIMATIC IPC647D

Technical specifications
8.4 Technical specifications
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
127
Interfaces
COM1; COM2 (optional)
Serial interface 1 (V.24), 9-pin D-sub connector
LPT (optional) Parallel
interface (Standard, EPP and ECP mode), connection
for printer with parallel interface
Double-row module connector (per ribbon cable at 25-pin sub
D connector)
VGA (optional) (DVI-I)
Connection of an analog monitor via DVI-I / VGA adapter
1 × DVI-I
For connecting a digital monitor
2 × DisplayPort
For connecting a digital monitor
2 × DisplayPort / DVI-D/VGA with
Dual Head graphics card (optional)
For connecting two digital or analog monitors DisplayPort,
DVI-D or VGA via DMS59 cable adapter
Keyboard
PS/2 keyboard connection
Mouse
PS/2 mouse connection
USB Rear of the device 2 × USB 3.0 high current
2 × USB 2.0 high current
Front panel 1 × USB 3.0 high current
1 × USB 2.0 high current
Internal
1 × USB 3.0 device high current
PROFIBUS (optional) 9-pin D-sub socket, CP5622-compatible, 9.6 Kbps to 12
Mbps, programmable with software:
DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
RS 485 electrically isolated (SELV circuit)*
PROFINET
4
3 × RJ45 interface, CP 1616 compatible onboard interface
based on ERTEC 400, 10/100 Mbps electrically isolated *
Ethernet
4
2 × Ethernet interface (RJ-45), Wake on LAN, Remote Boot
and teaming are supported.
10/100/1000 Mbps, electrically isolated *
Ethernet 1: WGI217LM, AMT-capable
1
, supports jumbo
frames up to 9014 bytes
Ethernet 2: Intel WGI210IT, supports jumbo frames up to
9014 bytes
Audio
- Microphone
- Line out / Headset
IDT 92HD81HD
2 × 0.5 W / 8 Ohm
*
Electrical isolation within the safety extra-low voltage circuit (SELV)
1
AMT and teaming cannot be used simultaneously on the Ethernet interface
