Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
41
Additional information is available in the catalog and the online ordering system Industry Mall
(http://mall.automation.siemens.com
).
Technical Support (http://www.siemens.de/automation/csi_en_WW)
The basic characteristics of the PCS 1616 onboard are:
● Optimized for PROFINET IO
● With Ethernet realtime ASIC ERTEC 400
● Three RJ45 sockets for connection terminal devices or addition network components
● Integrated 3-port real-time switch
● Automatic hardware detection
A maximum of one CP 1616/1604 is permitted
A maximum of one CP 1616/1604 module can be installed in one PG/PC. If you want to
use an additional CP 1616/1604 card, the CP 1616 onboard option must be disabled
using the "Profinet" entry in the BIOS setup.
