Siemens SIMATIC IPC647D

Expanding and assigning parameters to the device
6.5 Expansion cards
SIMATIC IPC647D
66 Operating Instructions, 01/2014, A5E32996306-AA
Removing a memory module
1.
Always remove the memory
modules in the reverse order:
1.
DIMM 1-2
2.
DIMM 1-1
3.
DIMM 2-2
4.
DIMM 2-1
2.
Open the two latches at the sides
of the memory module evenly.
Remove the memory module from
the slot.
3.
Close the device.
Display of the current memory configuration
The new memory configuration is detected automatically. The allocation of the ”base
memory and extended memory” is automatically displayed when you switch on the device.
