Overview
1.1 Product description
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
11
Basic data
Power supply
• 120 V / 230 V AC, 190 W; wide range
• 24 V DC, 210 W
AC and DC power supply with short-term power failure backup in
accordance with NAMUR: max. 20 ms at 0.85 rated voltage.
The 24 VDC power supply is isolated and protected against reverse
polarity connection.
Drives and storage media
Hard disk
• 1 × 3.5" ≥ 250 GB, SATA
• 2 × 2.5" ≥ 320 GB, SATA with RAID1 system for automatic data
mirroring on two hard disks
• 2 × 2.5" ≥ 320 GB, SATA in removable drive bay with RAID1
system for automatic data mirroring on two hard disks
also "Hot Swap" in connection with removable drive bay, hot spare
(at least 3 hard disks) is supported.
SSD (Solid State Disk)
2.5" ≥ 240 GB standard
USB stick
Can be connected externally via USB port and internally
DVD drive DVD burner slimline (optional)
• DVD+/-R/RW, CD, CD-RW, DVD-RAM
• Double layer functionality
Interfaces
Ethernet 2 × 10/100/1000 Mbps (two RJ45)
Wake on LAN, Remote Boot and teaming are supported
PROFIBUS/MPI
12 Mbps, electrically isolated, compatible with CP 5622 (optional)
PROFINET
3 × RJ45 ports, 10/100 bps, CP 1616 on-board (optional)
USB
• External: 4 × USB 3.0 high current
(a maximum of 2 can be operated as high current at the same
time)
• External: 1 × USB 2.0 high current, 1 × low current (optional)
• Internal: 1 × USB 3.0 high current for internal USB stick/dongle
COM
Serial V.24 port
COM2/LPT
optional
Monitor
• 1 x DVI-I (VGA monitors can be operated with a DVI/VGA adapter
acquired separately as an accessory)
• 1 x DisplayPort
