Technical specifications
8.5 Hardware descriptions
SIMATIC IPC627D/827D
122 Operating Instructions, 09/2014, A5E32990859-AB
8.5
Hardware descriptions
8.5.1
Motherboard
8.5.1.1
Structure and functions of the motherboard
The essential components of the motherboard are the processor and the chip set, two slots
for memory modules, internal and external interfaces and the Flash BIOS.
①
Processor heat sink
②
Slot for the bus board
③
Two memory module slots
