Technical specifications
8.4 Technical specifications
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
113
8.4
Technical specifications
8.4.1
General technical specifications
General technical specifications
Order numbers
See order documents
Dimensions IPC627D Without DVD burner/HDD in removable drive bay:
297 × 267 × 80 (B × H × T in mm)
With DVD burner/HDD in removable drive bay: 297 × 267 × 105
Dimensions IPC827D Without DVD burner/HDD in removable drive bay:
297 × 267 × 155 (B × H × T in mm)
With DVD burner/HDD in removable drive bay: 297 × 267 × 197
Weight IPC627D
approx. 5 kg
Weight IPC827D
approx. 7 kg
Supply voltage AC Nominal 100-240 V AC (-15% / +10%) (wide range)
Supply voltage DC
1
Nominal 24 V DC (-20% / + 20%), SELV
1
Input current AC
Continuous current up to 1.7 A (up to 50 A for 1 ms at startup)
Input current DC
Continuous current up to 7.1 A (up to 13 A for 50 ms at startup)
Line voltage frequency
50-60 Hz (47 to 63 Hz)
Short-term voltage interruption in
accordance with Namur
Max. 20 ms (at 93 to 264 V)
(max. 10 events/h; recovery time min. 1 s)
Max. power consumption AC and
DC
Active power 176 W
Degree of protection
IP 20 to IEC 60529
Protection class
Protection class I to IEC 61140
Safety specifications EN 60950-1; UL60950-1; CAN/CSA C22.2 No 60950-1-07;
UL508; CSA C22.2 No 142
Noise emission < 55 dB(A) according to EN ISO 7779
Quality assurance
In accordance with ISO 9001
1
The device should only be connected to a 24
V DC power supply which meets the re-
quirements of safe extra low voltage (SELV) according to IEC/EN/DIN EN 60950
-1. A
protective conductor must also be used (see section "
Connecting the 24 VDC power sup-
ply (Page 37)").
