Siemens SIMATIC IPC827D - Pin Assignment 12 V Power Supply Connection for Expansion Cards

Technical specifications
8.5 Hardware descriptions
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
129
5V System Environment
Side B
Side A
40
PERR#
SDONE
41
+3.3V
SBO#
42
SERR#
Ground
43
+3.3V
PAR
44 C/BE[1]# AD[15]
45
AD[14]
+3.3V
46
Ground
AD[13]
47
AD[12]
AD[11]
48
AD[10]
Ground
49
Ground
AD[09]
50
CONNECTOR KEY
51
CONNECTOR KEY
52
AD[08]
C/BE[0]#
53
AD[07]
+3.3V
54
+3.3V
AD[06]
55
AD[05]
AD[04]
56
AD[03]
Ground
57
Ground
AD[02]
58
AD[01]
AD[00]
59
+5 V (I/O)
+5 V (I/O)
60
ACK64#
REQ64#
61
+5V
+5V
62
+5V
+5V
8.5.2.3
Pin assignment 12 V power supply connection for expansion cards
Pin
Short description
Meaning
Input/Output
1 +12 V
1
12 V voltage Output
2
GND
Ground
-
3
GND
Ground
-
4
+5 V
1
5 V voltage
Output
1
max. permitted current: 1 A; with this power demand the total power demand for the PCI
slots are not allowed to be exceeded.
