Siemens SIMATIC IPC827D User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
117
8.4.2
Ambient conditions
Climatic conditions
Temperature
- Operation *
1
- Storage/transport
- Gradient
Tested according to IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14
+ 5 °C to + 45 °C
+ 5 °C to + 50 °C with a total power of max. 20 W for the USB and
PCI/PCIe expansions
+ 5 °C to + 55 °C with a total power of max. 10 W for the USB and
PCI/PCIe expansions
– 20° C to +60° C
max. 10° C/h in operation, 20° C/h storage, no condensation
Relative humidity
- Operation
- Storage/transport
tested to IEC 60068-2-78, IEC 60068-2-30
5% to 80% at 25° C (no condensation)
5% to 95 % at 25° C (no condensation)
Atmospheric pressure
- Operation
- Storage/transport
1080 to 795 hPa
(corresponds to an altitude of -1000 to 2000 m)
1080 to 660 hPa
(corresponds to an altitude of -1000 to 3500 m)
Mech. ambient conditions
Vibration
- Operation *
2,
*
3,
*
4
- Storage/transport
tested to DIN IEC 60068-2-6
10 to 58 Hz: 0.075 mm, 58 to 500 Hz: 9.8 m/s
2
5 to 9 Hz: 3.5 mm, 9 to 500 Hz: 9.8 m/s
2
Shock resistance
- Operation *
3
- Storage / transport
Tested to IEC 60068-2-27, IEC 60068-2-29
50 m/s
2
, 30 ms,
250 m/s
2
, 6 ms
*1
Restrictions for DVD burner drives:
Burning is only permitted with ambient temperatures of +5°C to +40°C. Reading is only
permitted with ambient temperatures up to a maximum of +50°C.
*2
Limitation with DVD burner drives:
10 to 58 Hz: 0.019 mm / 58 to 500 Hz: 2.5 m/s
2
Burning is only permitted in an interference-free environment
*3
Restriction for installation with vertical mounting kit:
Vibration: 10
-58 Hz: 0.0375 mm / 58-500 Hz: 4.9 m/s
2
Shock resistance: 25 m/s
2
, 30 ms
*4
Restriction for hard disk drives in removable drive bay:
No mechanical loads may occur at the device.
