Technical specifications
8.4 Technical specifications
SIMATIC IPC627D/827D
116 Operating Instructions, 09/2014, A5E32990859-AB
Interfaces
DVI-I
Connection of DVI monitor, with adapter also VGA monitor
DisplayPort
Connection of DisplayPort monitor
Keyboard
USB support
Mouse
USB support
USB 4 × USB 3.0, a maximum of 2 can be operated in high-current
mode at the same time
PROFIBUS / MPI interface, iso-
lated
- Transmission speed
- Operating modes
9-pin Cannon socket, 2-row
9.6 kbps to 12 Mbps
DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
PROFINET
3
RJ45 connector, CP1616 compatible, on-board interface on
ERTEC 400 basis, 10/100 Mbps electrically isolated
Ethernet
3
2 × Gigabit Ethernet interface (two RJ45) electrically isolated,
Wake on LAN, Remote Boot and teaming are supported
4 5
:
• X1P1: Intel WGI217LM (AMT interface),
supports jumbo frames up to 9014 bytes
• X2P1: Intel WGI210IT,
supports jumbo frames up to 9014 bytes
COM1
RS232, 115 kbps max., 9-pin SUB-D, male
Free slots for expansion cards
(see section "Motherboard")
• IPC627D: 2 PCI/PCIe cards
• IPC827D: 5 PCI/PCIe cards
3
For unique
labeling, the Ethernet interfaces are numbered on the enclosure. The numbering by the
operating system can differ.
4
No teaming with AMT.
5
When using AMT, the interface X1P1 must be used for connection to remote maintenance.
