Technical specifications
8.4 Technical specifications
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
115
Overview of slots and their specification
Slots for expansion cards IPC627D (bus module 2 x PCI)
Slot 1
PCI: Specification Rev. 2.2, length: Max. 185 mm
Slot 2
PCI: Specification Rev. 2.2, length: Max. 185 mm
Slots for expansion cards IPC627D (bus module 1 x PCI and 1 x PCIexpress)
Slot 1 PCI: Specification Rev. 2.2, length: Max. 185 mm
Slot 2
PCIexpress x16: Specification Rev. 3.0, length: Max. 185 mm
Slots for expansion cards IPC627D (bus module 2 x PCIexpress)
Slot 1
PCIexpress x4 (mech: x16): Specification Rev. 2.0, length: Max. 185 mm
Slot 2
PCIexpress x16: Specification Rev. 3.0, length: Max. 185 mm
Expansion card slots IPC827D
Slot 1
PCI: Specification Rev. 2.2, length: Max. 240 mm
Slot 2
PCI: Specification Rev. 2.2, length: Max. 240 mm
Slot 3
PCI: Specification Rev. 2.2, length: Max. 185 mm
Slot 4
PCIexpress x4 (mech: x16): Specification Rev. 2.0, length: Max. 185 mm
Slot 5
PCIexpress x16: Specification Rev. 3.0, length: Max. 185 mm
Drive and memory media
Hard disk drive 1 × 3.5" SATA-HD
2 × 2.5" SATA HD
Solid State Disk
1 × 2.5" SATA SSD, ≥ 240 GB Standard
DVD burner
Serial ATA, See order documentation for features
Graphics
Graphics controller
• Xeon: Intel® HD Graphics Controller P4600 GT2
• Core i3: Intel® HD Graphics Controller P4600 GT2
• Celeron: Intel® HD Graphics Controller
Graphics memory
32 - 512 MB Shared Memory
Resolutions/frequencies/colors DVI-I: 640 × 480 to 1920 × 1200 / 60 Hz / 24 bits
DisplayPort: max. 3840 ×2160 / 130 Hz / 30 bits
