Overview
1.1 Product description
SIMATIC IPC627D/827D
10 Operating Instructions, 09/2014, A5E32990859-AB
1.1.2
Features
Basic data
Installation
• Wall mounting
• Vertical mounting
Processor
• Intel Xeon E3-1268L v3 2.3 (3.3) GHz, 4 cores, GT2, 8 MB cache,
HT
• Intel Core i3-4330TE 2.4 GHz, 2 cores, GT2, 3 MB cache, AMT
• Intel Celeron G1820TE 2.2 GHz, 2 cores, GT1, 2 MB cache
Main memory Memory expansion up to 16 GB with the following memory modules:
without ECC:
• 2 GB DDR3 SDRAM
• 4 GB DDR3 SDRAM
• 8 GB DDR3 SDRAM
with ECC:
• 4 GB DDR3 ECC
• 8 GB DDR3 ECC
Possible configurations with
expansion cards
• IPC627D:
– 2 × PCI Rev. 2.2
– 1 × PCI Rev. 2.2, 1 × PCIe x16 Rev. 3.0
– 1 × PCIe x4 Rev. 2.0, 1 × PCIe x16 Rev. 3.0
• IPC827D:
– 3 × PCI Rev. 2.2, 1 × PCIe x4 Rev. 2.0, 1 × PCIe x16 Rev. 3.0
Graphics
• Intel® HD Graphics Controller P4600/4700 GT1/GT2
2D and 3D engine integrated in chipset
Dynamic Video Memory Technology
(occupies up to 512 MB in the main memory)
• DVI resolution of 640 × 480 pixels up to 1920 × 1200 pixels
• Graphics memory is claimed in main memory (dynamic UMA)
• Triple-head mode
DisplayPort resolutions depend on the graphics controller in the CPU,
which is represented by the processor:
• Celeron G1820TE: GT1 (HD Graphics),
maximum resolutions up to 2560 × 1600
• Core I3-4330TE: GT2 (HD Graphics 4600),
maximum resolutions up to 3840 × 2160
• XEON E3-1268L v3: GT2 (HD Graphics 4600)
maximum resolutions up to 3840 × 2160
