Technical specifications
8.6 BIOS description
SIMATIC IPC627D/827D
Operating Instructions, 09/2014, A5E32990859-AB
155
Power
System parameters
Default settings
Local settings
Wake on PME or LAN 2 (X2 P1)
Disabled
Auto Wake on S5
Disabled
Wake on S5 Time
1
00:00:00
Day of Month
1
1
Wake on LAN 1 (X1 P1)
Enabled
PROFINET always On
2
Disabled
PROFINET Wake Capability
2 3
Disabled
USB Ports 0/1 (X61/X60) powered
Enabled
USB Ports 0/1 (X61/X60) Wake
Capability
4
Disabled
USB Ports 4/5 (X63/X62) powered
Enabled
USB Ports 4/5 (X63/X62) Wake
Capability
4
Disabled
USB Ports 3/6/8/9 powered
Enabled
USB Port 3/6/8/9 Wake Capability
4
Disabled
1
Only visible if the "Auto Wake on S5" is set accordingly.
2
Visible depending on the ordered device configuration
3
Only visible if the parameter "PROFINET always On" is enabled.
4
Only visible if the associated parameter "USB Ports # powered" is enabled.
Power > Advanced CPU Control
System parameters
Default settings
Local settings
P-States (ACTUAL)
Enabled
Active Processor Cores
All Cores
HT Support
Auto
Execute Disable Bit
Enabled
Intel (VMX) Virtualization Technology
Enabled
C-States
Enabled
Turbo Mode Enabled
Boot
System parameters
Default settings
Local settings
Boot Type
Dual Boot Type
Quick Boot Enabled
Quiet Boot
Enabled
Network Stack
Disabled
PXE Boot capability
Disabled
Add Boot Options
Auto
USB Boot
Enabled
EFI Device First
Enabled
Boot Delay Time
3
