Overview
1.1 Product description
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA
13
General features
Interfaces
PROFIBUS/MPI 12 Mbps (electrically isolated, compatible with CP 5622),
optional
PROFINET
10/100 Mbps (CP 1616 onboard), three RJ45; optional
Ethernet 2 × 10/100/1000 Mbps (two RJ45)
Wake on LAN, Remote Boot and teaming are supported
USB
2 × front panel, 4 × rear panel, 1 × internal; (high current)
Serial
COM1 (V.24), COM2 (V24) optional
Parallel
LPT, optional
Monitor
• 1 × DVI-I (for DVI-D or VGA using cable adapter)
• 2 × DisplayPort
• 2 × DisplayPort / DVI-D/VGA with Dual Head graphics
card (optional)
Keyboard
PS/2
Mouse
PS/2
Audio
Microphone, Line out / Headset
Power supply 100 VAC to 240 VAC, wide range; with short-term power
failure backup in accordance with NAMUR: Max. 20 ms at
0.85 rated voltage
Monitoring functions
Temperature
• Overshoot/undershoot of permissible operating
temperature
• Messages can be evaluated by an application program.
Fan
• Speed monitoring
• Messages can be evaluated by an application program.
Watchdog
• Monitoring of the IPC
• Monitoring time can be parameterized in software
• Restart can be parameterized in the event of a fault
• Messages can be evaluated by an application program.
Status LEDs
• POWER (internal power supply unit, PC switched On)
• ETHERNET 1, ETHERNET 2 (Ethernet status)
• PN Ι MPI/DP (activity display of the PROFIBUS/MPI
interface, optional product feature or status display of the
CP 1616 onboard interface, optional product feature)
• WATCHDOG (Watchdog function/error display)
• TEMP (temperature status)
• FAN (speed monitoring)
• HDD0 Alarm, HDD1 Alarm, HDD2 Alarm, HDD | HDD3
Alarm: Access to hard disk and with RAID option: RAID
status message in conjunction with SIMATIC monitoring
software
