Siemens SIMATIC IPC847D - Securing the Lines; Basic Power Supply

Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC847D
48 Operating Instructions, 01/2014, A5E32997454-AA
3.3.6
Securing the lines
3.3.6.1
Basic power supply
Secure the power supply plug, if necessary, to prevent the power cables from becoming
loose accidentally.
Procedure
1.
Remove the fixing screw
② at the power
supply.
2.
Remove the connector lock ②
at the
power supply.
WARNING
Fire hazard
If the power supply plug is secured with a connector lock, the power outlet must be freely
accessible to allow the device to be easily removed from the mains.
