8.5 Hardware description
SIMATIC IPC847D
156 Operating Instructions, 01/2014, A5E32997454-AA
8.5.2.2
Pin assignment of the bus board connectors
PCI slot connector pin assignment
5V System Environment
Side B
Side A
1
-12 V
TRST#
2
TCK
+12 V
3
Ground
TMS
4
TDO
TDI
5
+5 V
+5 V
6
+5 V
INTA#
7
INTB#
INTC#
8
INTD#
+5 V
9
PRSNT1#
Reserved
10
Reserved
+5 V (I/O)
11
PRSNT2#
Reserved
12
Ground
Ground
13
Ground
Ground
14 Reserved Reserved
15
Ground
RST#
16
CLK
+5 V (I/O)
17
Ground
GNT#
18
REQ#
Ground
19
+5 V (I/O)
Reserved
20 AD[31] AD[30]
21
AD[29]
+3.3 V
22
Ground
AD[28]
23
AD[27]
AD[26]
24
AD[25]
Ground
25
+3.3 V
AD[24]
26
C/BE[3]#
IDSEL
27
AD[23]
+3.3 V
28
Ground
AD[22]
29
AD[21]
AD[20]
30
AD[19]
Ground
31
+3.3 V
AD[18]
32
AD[17]
AD[16]
33
C/BE[2]#
+3.3 V
34
Ground
FRAME#
35
IRDY#
Ground
36
+3.3 V
TRDY#
