Technical specifications
8.4 Technical data
SIMATIC IPC847D
130 Operating Instructions, 01/2014, A5E32997454-AA
8.4.5
AC power supply, redundant
Output voltage
Voltage
Max. current
Voltage stability
+ 12 V
18 A
2
+/- 5 %
+ 12 V
18 A
2
+/- 5 %
+ 12 V
14 A
2
+/- 5 %
- 12 V
0.8 A
+/- 10 %
+ 5 V
20 A
1
+ 5 % / - 4 %
+ 3.3 V
20 A
1
+ 5 % / - 4 %
+ 5 Vaux
2.0 A
+ 5 % / - 3 %
1
The accumulated power of the +5 V and + 3.3 V supply may not exceed 100 W.
2
The maximum accumulated current of the +12 V voltage must not exceed 24 A.
The maximum inrush current is for:
110 V AC: 25 A, 5 ms
230 V AC: 30 A, 5 ms
8.4.6
Technical data of the telescopic rails
Ultimate load per pair
At least 23 kg
Full extraction length
At least 470 mm
Rail thickness
Maximum 9.7 mm
Mounting screws
M5 x 6 mm
