Commissioning the device
4.2 Switching on the device
SIMATIC IPC847D
54 Operating Instructions, 01/2014, A5E32997454-AA
Following the initial switch on, the operating system is set up automatically on the device.
If you change the default values in the BIOS setup or if you turn off the device during
installation, you disrupt the installation and the operating system is not installed correctly.
The operating safety of the device and the plant is at risk.
Do not switch off the device during the entire installation process. Do not change the defau
values in the BIOS setup.
1. Set the on/off switch to position "1". Information on the position of the switch is available
in the section "Operator Controls (Page 17)".
2. Press the on/off button.
The green "POWER" LED lights up. The module carries out a self-test. During the self-
test, the following message appears:
Press <ESC> to go to the main BIOS menu
3. Wait for the message to disappear. Then Windows is started.
4. Follow the instructions on the screen.
Note
The following steps are only to be performed for initial startup of the
device with factory
5. Make the required region and language settings.
If you want your system language to be international, select English. Information on
changing the regional and language settings at a later time is available in the section
"Setting up the language selection by means of the Multilanguage User Interface (MUI)".
Note
Once the operating system has been set up, the device may restart.
6. Type in the product key as required.
The product key is located on the "Certificate of Authentication" in the "Product Key" line,
see section "Identification data of the device (Page 36)".
The interface of the operating system is displayed every time you turn on the device and
after the startup routine.
