Siemens SIMATIC IPC847D - 6.5 Drives

Expanding and assigning parameters to the device
6.5 Drives
SIMATIC IPC847D
76 Operating Instructions, 01/2014, A5E32997454-AA
6.5
Drives
6.5.1
Installation options of drives
In the front drive cage
Item
Description
①
Front drive cage
②
Bay for optical slimline
drive
③
1-4 bays for hard disk
removable drive bays
④
Design covers for
removable drive bays
Note
Removable drive bay adapter
Adapters for one or three removable drive bays are available for installation of
removable
racks in the front drive cage.
In the rear drive cage (with vibration damping)
Item
Description
①
Rear drive cage
②
Two bays for hard disk
drives (with shock and
vibration damping)
