Technical specifications
8.6 BIOS description
SIMATIC IPC847D
178 Operating Instructions, 01/2014, A5E32997454-AA
8.6.6
BIOS Setup settings
If you have changed any default settings in Setup, you can enter them in the following table.
You can then refer to these entries for any future hardware modifications.
Note
Print out the table below and keep the pages in a safe place once you made your entries.
The default setup settings vary
depending on the ordered device configuration.
BIOS Setup settings
Main
System parameters
Default settings
Local settings
System Time
00:00:00
System Date
MM/DD/YYYY
Advanced > Boot Configuration
System parameters
Default settings
Local settings
Numlock
On
POST errors
All without keyboard
Advanced > Peripheral Configuration
System parameters
Default settings
Local settings
Internal COM 1
1
Auto
Base I/O address
1
3F8
Interrupt
1
IRQ4
Internal COM 2
1
Auto
Base I/O address
1
2F8
Interrupt
1
IRQ3
Internal LPT
1
Auto
Base I/O address
1
378
Interrupt
1
IRQ7
Mode
1
Bi-directional
DMA Channel
1
DMA 1
Onboard PROFINET
1
Enabled
PCI – MPI / DP
1
Enabled
Audio
Auto
Onboard Ethernet 1 (LAN 1, X1 P1)
Enabled
Onboard Ethernet 2 (LAN 2, X2 P1)
Enabled
1
Visible depending on the ordered device configuration
