Overview
1.1 Product description
SIMATIC IPC847D
12 Operating Instructions, 01/2014, A5E32997454-AA
Design
• 19” rack, 4 HU
• Rugged panel-mount housing, all metal
• Prepared for mounting telescopic rails
• Horizontal and vertical mounting position is possible
• Tower installation by means of Tower Kit
• Lockable front cover as access protection
Enclosure
•
Dust protection by means of overpressure ventilation using
bearing seated front fan through filter
• Enclosure cover fastened with a single screw
• Front fan can be exchanged without tools
• Card retainer for reliable operation of PC modules under
vibration and shock conditions
Drive bays
• Front:
– 3 × 5.25" or
– 1 × 5.25" and maximum 3 × slimline removable drive
bays or
– 4 × slimline removable drive bays
and 1 × slimline format for DVD burner
• Internal: 2 × 3.5" (fixed installation or in vibration-damping
drive cage)
Slots for expansion cards (long) Variant 1:
• 7 × PCI
• 3 × PCIe x4
• 1 × PCIe x16
Variant 2:
• 3 × PCI
• 5 × PCIe x16
• 3 × PCIe x4
total of up to 11 expansion cards simultaneously
Graphics
• CRT (via DVI-I VGA adapter): up to 2560 × 1600 at 120
Hz / 32-bit color depth
• LCD via DVI-D: up to 2048 × 1152 at 60 Hz / 32-bit color
depth
• LCD via DisplayPort: up to 4096 × 1152 at 24Hz / 32-
bit color depth
