Siemens SIMATIC IPC847D User Manual

Expanding and assigning parameters to the device
6.2 Open the device.
SIMATIC IPC847D
70 Operating Instructions, 01/2014, A5E32997454-AA
Limitation of liability
All technical data and approvals apply only to expansion units which are released by
SIEMENS.
Siemens does not accept any liability for impairment of functions caused by the use of third-
party devices or components.
Observe the installation instructions for the components. UL approval of the device only
applies when the UL-approved components are used according to their "Conditions of
Acceptability".
Procedure
1.
Open the front panel.
2.
Loosen the indicated screw.
The screw stays captive in the
housing.
3.
Push the cover to the
back and
remove it pulling up.
Closing the device
Proceed in reverse order.
