Recommended procedure - Part II: Software
Table 8-2 Recommended commissioning procedure - Part II: Software
Tasks Remarks Information is found in
...
• Switch on the PG
and start SIMATIC
Manager
• Download the
configuration and the
program to the CPU
- in the STEP 7
Programming Manual
Testing the I/Os Helpful functions are here:
• Monitoring and controlling of variables
• Testing with program status
• Force
• Controlling outputs in Stop mode (PA
isolation)
Tip: If you connect switches to the inputs, you
can include the signal lines in your test.
• in the STEP 7
Programming Manual
• in Chapter Testing
Functions, Diagnostics
and Fault Elimination
Commission
PROFIBUS-DP or other
networks
- in Chapter Commissioning
PROFIBUS-DP
Connect the outputs Commissioning the outputs successively. -
Danger
Proceed step-by-step. Do not go to the next step unless you have verified the
previous one without error/error message.
Reaction to errors
React to errors as follows:
• Check the system with the help of the Checklist in the chapter below.
• Check the LED displays on all modules. Notes on their significance is found in
the chapters describing the respective modules.
• If required, remove specific modules to trace the error.
Important notes are also found ...
in Chapter Testing Functions, diagnostics and fault elimination
