Commissioning
S7-300 Programmable Controller Hardware and Installation
A5E00105492-01
8-13
8.6.2 Initial power on
Prerequisites
• The S7-300 is installed and wired.
• A SIMATIC MMC is inserted in the S7-300 with CPU 31xC.
• The mode selector switch is set to STOP.
Initial Startup of CPUs 31x
Switch on the PS 307 power supply module.
Result:
• The 24 VDC LED on the power supply module is lit.
• The 5 VDC LED on the CPU
– is lit.
– The STOP LED flashes at 2 Hz when the CPU executes an automatic
memory reset.
– The STOP LED is lit after memory reset.
The BATF LED is lit if the backup battery is missing in the CPU (not with
CPU 312 IFM, since not buffered).
Note
If you insert a Memory Card and a backup battery before power is on, the CPU
also requests a memory reset after startup.
Initial Startup of CPUs 31xC
Switch on the PS 307 power supply module.
Result:
• The 24 VDC LED on the power supply module is lit.
• The 5 VDC LED on the CPU
– is lit.
– The STOP LED flashes at 2 Hz when the CPU executes an automatic
memory reset.
– The STOP LED is lit after memory reset.
8.6.3 Resetting CPU memory
When do you reset CPU memory?
You must reset CPU memory,
• Before you download a (completely) new user program to the CPU
• If the CPU requests memory reset with its STOP LED flashing at 0.5 Hz
intervals Possible reasons for this request are listed in the table below .

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
