Wiring
S7-300 Programmable Controller Hardware and Installation
6-2 A5E00105492-01
Tools and material required
To wire the S7-300, you require the tools and materials listed in the table below.
Table 6-2 Tools and material for wiring
You require ... for ...
bonding the protective conductor to the
profile rail
Wrench
Protective conductor cable (cross-
section ≥ 10 mm
2
) with M6 cable lug
M6 nut, washer, spring lock washer
Adjusting the power supply module to mains
voltage
Screwdriver with a blade width of 4.5 mm
Wiring the power supply module and the
CPU
Screwdriver with a blade width of 3.5 mm,
side-cutter, wire stripping tool
Flexible cable, e.g. sheathed flexible cable
3 x 1.5 mm
2
If required, wire end ferrules to DIN 46228
Wiring the front connector Screwdriver with a blade width of 3.5 mm,
side-cutter, wire stripping tool
Flexible cable 0.25 mm
2
to 0.75/1.5 mm
2
If required, shielded cables
If required, wire end ferrules to DIN 46228
Brief overview of the power supply module and CPU
Table 6-3 Conditions for wiring the PS and CPU
Connectable cables to PS and CPU
solid conductors No
flexible conductors
• Without wire end ferrule
• With wire end ferrule
0.25 mm
2
to 2.5 mm
2
0.25 mm
2
to 1.5 mm
2
Number of conductors per terminal 1 conductor, or 2 conductors up to 1.5 mm2
(total) in a common wire end ferrule
Diameter of the conductor insulation max. 3.8 mm
Stripped length 11 mm
Wire end ferrules to DIN 46228
• Without insulating collar
• With insulating collar
Version A, 10 mm to 12 mm length
Version E, up to 12 mm length
Brief overview of front connectors
Table 6-4 Wiring conditions for front connectors
