Siemens SIMATIC S7-300 Module data Hardware And Installation Manual

S7-300 Programmable Controller Hardware and Installation
A5E00105492-01
5-1
5Installation
5
5.1 Installation
In this chapter
we explain the steps required for the mechanical assembly of an S7-300.
Note
Note the installation guidelines and notes on safety in this manual when mounting,
commissioning and operating S7-300 systems.
Open components
S7-300 modules are "Open Components" according to IEC 61131-2 and EC
Guideline 73/23/EEC (Low-Voltage Guideline), and to UL/CSA Approval an "open
type".
In order to conform with specifications on safe operation relating to mechanical
strength, inflammability, stability and touch-protection, the following alternative
installation modes are prescribed:
• Installation in a suitable cubicle
• Installation in a suitable cabinet
• Installation in an appropriately equipped and closed operating area
Access to these areas must only be possible with a key or tool. Only trained or
authorized personnel is allowed access to these cubicles, cabinets or electrical
operating rooms.

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
