Siemens SIMATIC S7-300 Module data Hardware And Installation Manual

Configuring
S7-300 Programmable Controller Hardware and Installation
A5E00105492-01
4-19
N
L1
L+
M
PS
S7-300 CPU
µP
L1
N
M
external
L+
U
internal
M
internal
Data
L1
N
DI
DO
PE
Ground bus in
cabinet
AC 230 V load
power supply
DC 24 V load power supply
* In the case of CPU 31xC or 312 IFM, the connection is automatically established.
*
Figure 4-9 Configuration with isolated modules
Non-isolated modules
In configurations with non-isolated modules, the reference potentials of the control
circuit (M
internal
) and load circuit (
M
external) are not electrically isolated (see the
figure below ).
Example:
For operation with an SM 334 AI 4/AO 2 analog I/O module you must connect one
of the grounding terminals M
analog
to the CPU's chassis ground.
The figure below shows a sample configuration of an S7-300 CPU with non-
isolated modules.

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
