Siemens SIMOCODE pro PCS 7 User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
145
Auxiliary variables
Diag_Wrn
bit
Event
12
Warning level I>
13 Warning level I<
14
Warning level P>
15
Warning level P<
16
Warning level cos phi<
17
Warning level U<
18
Warning level 0/4–20 mA>
19
Warning level 0/4–20 mA<
20
Stalled rotor
21
No start permitted
22
Number of starts >
23
Just one start possible
24
Motor operating hours >
25
Stop time >
26
External fault 1
27
External fault 2
28
External fault 3
29
External fault 4
30
External fault 5
31
External fault 6
32
AM open circuit
33
DM-F safety-related tripping
34 DM-F test requirement
35
DM-F feedback circuit
36 DM-FL simultaneity
43
EM open circuit
44
EM short circuit
Table 4- 57
Bit assignment Diag_Wrn for SIMOCODE pro PROFINET devices
Diag_Wrn
37
TM2 warning T>
38
TM2 sensor fault
39
TM2 Out of Range
40
AM2 Warning 0/4–20 mA>
41
AM2 Warning 0/4–20 mA<
42
AM2 open circuit
