Siemens SIMOCODE pro PCS 7 User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
146 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Bit assignment Diag_Trp
Table 4- 58
Bit assignment
Diag_Trp
for SIMOCODE pro PROFIBUS devices
Auxiliary variables
Diag_Trp
bit
Event
Diag_Trp
0
Hardware fault basic unit
1 Module fault
2
Temporary components
3
Configuration fault
4
Parameterization
5
Bus
6
PLC/PCS
7
Runtime On
8
Execution Stop command
9
FB ON
10
FB OFF
11
Stalled positioner
12
Double 0
13
Double 1
14
End position
15
Antivalence
16
Cold starting (TPF) error
17
UVO fault
18
OPO error (operational protection OFF)
19
Unbalance
20
Overload
21
Overload + phase failure
22 Internal ground fault
23
External ground fault
24 Thermistor overload
25
Thermistor short circuit
26
Thermistor open circuit
27
TM trip T>
28
TM sensor fault
29
TMOut of Range
30
Trip I>
31
Trip I<
32
Trip level P>
33
Trip level P<
34
Trip level Cos-Phi<
35
Trip level U<
36
Trip level 0/4–20 mA>
37
Trip level 0/4–20 mA<
