Siemens SIMOCODE pro PCS 7 User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
147
Auxiliary variables
Diag_Trp
bit
Event
38
Stalled rotor
39 Number of motor starts>
40
External fault 1
41
External fault 2
42
External fault 3
43
External fault 4
44
External fault 5
45
External fault 6
46
Analog module open circuit
47
Test trip
48
DM-F safety-related tripping
49
DM-F wiring
50
DM-FL cross circuit
57
EM open circuit
58
EM short circuit
Table 4- 59
Bit assignment
Diag_Trp
for SIMOCODE pro PROFINET devices
Diag_Trp
51
TM2 trip T>
52
TM2 sensor fault
53
TM2 Out of Range
54
AM2 Warning 0/4–20 mA>
55
AM2 Warning 0/4–20 mA<
56
AM2 open circuit
