Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
247
Parameter
Data format
Default setting
Meaning
ExtVa208
ANY
–
External value 8 (MsgEvID2)
ExtVa209 ANY – External value 9 (MsgEvID2)
ExtVa210
ANY
–
External value 10 (MsgEvID2)
SelFp1 ANY – Select Faceplate 1
SelFp2
ANY
–
Select Faceplate 2
SelFp3
ANY
Select Faceplate 3
OS_Perm STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 1
• 1
• 1
Operator permissions
Feature STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 0
• 0
• 0
Status of various features
OpSt_In
DWORD
16#00
Enabled operator stations
ReserveIn
WORD
16#00
Reserved
Output parameters
Table A- 12 Output parameter MMOprtn
Parameter
Data format
Default setting
Meaning
RackF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack failure
ModF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module failure
RdErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error read record
WrErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error write record
RdErrStat
WORD
16#00
Status of read record error
WrErrStat
WORD
16#00
Status of write record error
RdWrAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Operator enabled for read / write record
