A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
248 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
RdDataOut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Triggers Read operation of DS92 at MMDiag
ExMsgOu1 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 1 at Event16Ts
ExMsgOu2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 2 at Event16Ts
ExMsgOu3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 3 at Event16Ts
ExMsgOu4 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 4 at Event16Ts
ExMsgOu5 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 5 at Event16Ts
ExMsgOu6 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 6 at Event16Ts
ExMsgOu7 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 7 at Event16Ts
ExMsgOu8 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 8 at Event16Ts
AM1OutRng STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog module 1 – Measuring range output
AM1InRng STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog module 1 – Measuring range input
AM2OutRng STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog module 2 – Measuring range output
