Siemens SIMOCODE pro PCS 7

Parameter
A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
255
Parameter
Data format
Default setting
Meaning
ExtMsg7 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 7
ExtMsg8 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 8
ExtVa104
ANY
–
External value 4
ExtVa105
ANY
–
External value 5
ExtVa106
ANY
–
External value 6
ExtVa107
ANY
–
External value 7
ExtVa108
ANY
–
External value 8
ExtVa109
ANY
–
External value 9
ExtVa110
ANY
–
External value 10
OS_Perm STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 1
• 1
• 1
Operator permissions
OpSt_In
DWORD
–
Enabled operator stations
Feature STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 0
• 0
• 0
Status of various features
ReserveIn
WORD
16#00
Reserved
Output parameters
Table A- 14 MMMeas output parameter
Parameter
Data format
Default setting
Meaning
RackF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack failure
ModF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module failure
RdErrStat
WORD
16#00
Status of read record error
GrpErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Group error is active
